1080P 120fps High Speed USB Camera 12MP Webcam IMX577 4K 30fps for Streaming Teaching Machine Vision PC Laptop Raspberry Pi
Original price was: $137.37.$131.51Current price is: $131.51.
496 in stock
1. Ultra HD 3840*3040 High Resolution 12MP USB Camera.
2. With industrial grade high quality sensor Sony IMX577.
3. High frame rate 20fps 12 megapixel usb camera, can do 120fps@1920*1080.
4. High quality 3.6-10mm varifocus CS lensl;
5. With 3m usb cable (2/3/5m optional)
6. Low illumination 0.1Lux, work well in low light environment.
7. Super Image reality, real color reproduction, without interpolation.
8. UVC Complaint, Free Driver , Plug and Play, easily used on different systems.
9. Mini size 38*38mm, super small outline and thin profile for embedded applications;
10. Support Windows, Linux, Android, Mac OS, Ubuntu, Raspberry Pi…8.OTG Support, can be used on Android smartphone, recommended app “USB Camera”.
11.Wide Application: Well used for High Resolution Document Scanning, High-speed photographic apparatus, Photo scanner, Medical device, Industrial Inspection, Scientific research and development ,Education and Training, Video Conferencing, Live Streaming, Security and so on.
|
Model NO.:
|
ELP-USB12MP01-UFV(3.6-10) |
|
Image Sensor
|
SONY IMX577 (1/2.3” )
|
|
Max. Resolution
|
3840(H) *3040 (V)
|
|
Sensor Size/Image Size
|
10.7mmX8.5mm/ 5.95mmX4.71mm
|
|
Default. Resolution
|
3840(H) *2880(V)
|
|
Compression Format
|
MJPEG / YUY2(YUYV)
|
|
Resolution&Frame Rate
|
3840X3040 MJPEG@20fps YUY2@1fps
3840X2880 MJPEG@20fps YUY2@1fps 3840X2160 MJPEG@30fps YUY2@1fps 2592X1944 MJPEG@30fps YUY2@1fps 2048X1536 MJPEG@30fps YUY2@3fps 1600X1200 MJPEG@30fps YUY2@5fps 1920X1080 MJPEG@120fps YUY2@5fps 1280X960 MJPEG@120fps YUY2@5fps 1280X720 MJPEG@120fps YUY2@5fps 1024X768 MJPEG@120fps YUY2@5fps 960X720 MJPEG@120fps YUY2@5fps 800X600 MJPEG@120fps YUY2@20fps 640X480 MJPEG@120fps YUY2@30fps 320X240 MJPEG@120fps YUY2@30fps |
|
Center Definition
|
1000LW/PH (Center)
|
|
S/N Ratio
|
24dB
|
|
Sensitivity
|
0.65V/lux-sec@550nm
|
|
Minimum illumination
|
0.1lux
|
|
Shutter Type
|
Electronic rolling shutter / Frame exposure
|
|
Connecting Port type
|
USB2.0 High Speed
|
|
AEC/ AWB/ AGC
|
Support
|
|
Adjustable Parameters
|
Brightness, Contrast, Hue, Saturation, Sharpness, Gamma, White
Balance, Exposure |
|
Lens Parameter
|
No distortion M12 lens, 2.1/2.8/3.6/6/8/12mm lens/no distortion lens/fisheye lens optional, lens changeable.
|
|
Power Supply&Connector
|
USB BUS POWER 4P-2.0mm socket
|
|
Power Voltage
|
DC 5V
|
|
Power Current
|
240mA
|
|
Board Size
|
38mm × 38mm
|
|
Storage Temperature
|
-20°C to 85°C
|
|
Working Temperature
|
-10°C to 65°C
|
|
USB Cable
|
1M(2M/3M/5M optional)
|
|
Operating System Support
|
Win XP/Vista/Win7/Win8 /Win9/Win10/Win11 etc.
Linux with UVC（above linux-2.6.26） MAC-OS X 10.4.8 or later Android 4.0 or above with UVC |
12MP 3840*3040 USB camera
MJPEG 120fps 1920X1080, MJPEG 30fps at 3840*2160
3.6-10mm varifocus CS lens
Compression: Mjpeg/YUY2
UVC, Plug & Play
0.1Lux Low Light
High-quality USB camera adopted Sony IMX577 image sensor with max resolution 3840X3040 for great picture performance, keep the purity and clarity of images.
120FPS High Speed: With this high-speed UVC camera module, you can enjoy programmable frame rates, with the potential to reach up to MJPEG 120fps 1920X1080 and MJPEG 30fps at 3840*2160 resolution
3X Manual Optical Zoom Lens: 3.6-10mm manual focus and zoom lens enable 1X optic zoom total 3X zoom for super clear details image
Plug&Play, UVC compliant, just connect the camera to PC, laptop, Android device or Raspberry Pi with the included USB cable without extra drivers to be installed
FOR PC:
* Support windows,linux,mac,Android,raspberry Pi
* Very easy to use,UVC compliant,free driver,just plug in and go.
FOR RASPBERRY PI
* It can work with already preinstalled camera software instead of builtin camera.
* Support Android development board,Raspberry Pi development board,Jetson Nano,etc
Low illumination 0.1Lux, work well in low light environment
Ideal for many applications like ATM Machine, Robot, PC, Kiosk,Security Systems, Portable Video System, Video Phones, Industrial Machine Monitoring, Remote Site Monitoring and Toys etc
| Weight | 12 kg |
|---|---|
| Dimensions | 11 cm |
| Brand Name | ELP |
| Hign-concerned Chemical | None |
| Origin | Mainland China |
| Model Number | ELP-USB12MP01-UFV(3.6-10) |
| Certification | RoHS |
| Max.resolution | 3840*3040 |
| Imgae sensor | 1/2.3" SONY IMX577 |
| Picture format | MJPEG or YUY2 optional |
| free driver | USB Video Class(UVC)1.1 |
| Lens | 3.6-10mm varifocus lens |
| cable | 3m(2/3/5m optional) |
| Board size | 38x38mm,32x32mm |
| OS | Windows, Linux, Android, Mac OS |
