Name: NEJE 120W Metal Cutting Laser Module Kits 450nm Blue Light TTL Module for Laser Engraver Wood Cutting Smarter Tool Air Assist
SKU: 3256803920263784
Availability: InStock

NEJE 120W Metal Cutting Laser Module Kits 450nm Blue Light TTL Module for Laser Engraver Wood Cutting Smarter Tool Air Assist

$85.00 – $233.82

FAQs:

【Stainless Steel Engraving】Engraving stainless steel only needs a small enough focus point and enough light power, E30130, A40640, A40630 and A30130 module can directly engrave stainless steel, and N30820 and N40630 modules can engrave stainless steel by painted.

【100% Satisfaction】NEJE factory are proud to provide the process of 48-hour temperature control for aging test to ensure the quality of each module and guaranteed 2 years (20,000 hours) free warranty.

A40640(Artist's Choice) is a classic creative master 2 beam zoom laser module, it is the world's first 2 beam laser diode engraving and cutting module with zoom design, with the best metal engraving ability, fast groove engraving ability, perfect cutting compatibility. Better application on a wider range of materials, The strongest power density (0.04×0.06mm with 12W+ pulse and 11W continuous optical power, Use 80% power (9W+) when cutting for a long time)of enables the A40640 to have the top engraving ability, There are very special and top artistic expressions on the carvings of stainless steel grayscale carvings, stone carvings, Glass Carving, hardwood reliefs, canvas art, and other materials. The adjustable focal length design enables the A40640 module to have a uniform cutting thickness of 20mm and short-focus fast cutting capabilities. If you only consider 1 module to help you solve all the needs, it is the best choice.

E40 is 2 beam fixed module with 11W pulse and 10W+ continuous power output capability, Same engraving capability as A40640, It is a carving and cutting module with high cost performance and wide application

E30130,are the series of fixed focus modules specially designed by NEJE for cutting and directly use it for engraving with ACO air pump. These Laser modules are fixed focal length modules, which require clean air source support, E30130 is 20mm focal length, through internal NEJE optical processing, the spot shape is square, suitable for cutting materials with strong symmetry requirements such as model aircraft

NEJE E80 – UNIQUE INDUSTRIAL PERFORMANCE AND DURABILITY MODULE

It adopts a unique solution that does not damage the original LD optical structure, retains the reliability and durability of the original LD, and has a service life up to 10 times longer than all other 20W output laser modules and CO2 modules. The production process of the E80 module is more complex, and currently only the NEJE team has completed batch manufacturing. It has a longer lifespan. Each module has an original SN registration number, and users can register SN registration information to enjoy after-sales protection of no less than 70% attenuation for up to 2 years. NEJE E80 has great advantages in terms of lifespan.

Hybrid compression technology makes the focal point of NEJE E80 0.06×0.06mm, the symmetrical XY shape make it achieve the ultimate in carving and cutting performance and the power density reaches 6666W/mm², Compared with 40W(output) module,power density:1777W/mm² (0.15×0.15mm,8xLD,Current highest power) , the performance of E80 is more higher than the 40W module. Due to the extremely strong power density and optical design (symmetrical XY shape), NEJE E80 has more excellent performance.

E80 is a quasi-industrial-grade fixed-focus module. Unlike CO2 lasers, the 450nm semiconductor laser is visible, and the intensity of weak light can be set. Observe the minimum focus by observing the fluorescence reflected on the surface of the gray cardboard through protective glasses Location.

NEJE E80 recommends using NEJE Max 4 equipment control, through variable Z-axis multi-layer sinking settings, cutting from the material surface layer by layer to achieve high efficiency purpose of cutting.

NEJE A40630 laser module

NEJE E30130 laser module

ABOUT AIR ASSIST

When do you need air assist?

Air-assisted engraving or cutting can only be used for engraving or cutting that produces more carbonized substances. Generally, the depth of engraving is less than 1mm, and the cutting of plywood less than 2mm does not require air assist. A small fan can be used to blow off the smoke generated by the engraving. Air assist is not recommended when engraving images, and adding air assist at this time will destroy image details.
