Sale!

NEJE 3 Plus PLUS A40630 CNC Metal Laser Engraver Wood Cutting Machine Stainless Steel Engraving Tools With Bluetooth App Control

Original price was: $539.61.Current price is: $216.10.

NEJE 5 Plus A40630
50W
Clear

FEATURE

【Open operating platform】Just fit on a desktop with a width of 600mm, and the left side of the machine is not limited by the size of the material. It is suitable for processing large area materials. Under the protection of the MEMS vibration protection sensor, the engraving and cutting processes can be completed at the same time. The X-axis motion module is only 120g and is driven by a 40mm thick high-performance stepper motor, bringing a faster engraving experience than the gantry structure, 3400 x 5600 pixels, engraving accuracy: 0.075 mm dot pitch, 338 dots/inch. The whole machine function test requires only 4 screws to complete the installation.
【Top engraving performance】The laser beam is composed of two high-power laser diodes. Using NEJE's unique optical technology, the engraving is clearer than ordinary combined lasers. The minimum focus point reaches 0.04×0.06mm (A40640 module), 12W optical power pulse output, 11W constant power output, high energy density can instantly vaporize the engraving material, and achieve a plasma-level engraving experience. Built-in fast-response intelligent drive, stable current Control, temperature feedback, intelligently adjust fan cooling, and configure all-round static elimination technology. Safe and quiet to use.
【More clearer, Safer】 No stray light interference, clear texture, high energy density, lightweight design is the secret of A40640 becoming the king of engraving, A40640's excellent optical design, complex optical and safety drive design, everything is for more powerful clear Engraving and safe use. The motherboard has built-in MEMS protection. When the device is working, the MEMS gyroscope will automatically record the device status to prevent accidental touch.
【Portable professional control software】32-bit control system, the fastest speed can reach 200,000mm/min, supports LaserGRBL, Lightburn, NEJE software, NEJE APP (Android, iOS, ipadOS, macOS), you can change it by taking photos with your mobile phone or selecting images from the album To complete the work quickly, NEJE provides free software upgrade services.
【Perfect after-sales service]】10 years of technical precipitation makes the NEJE team confident to provide a 2-year free after-sales commitment. NEJE is also the only laser engraving company that has direct factory after-sales and establishes a complete after-sales process.

SPECIFICATION

Framesize (L – W -H): 550x480x140mm
Working area( X – Y): 255 x 420mm
Dot Pitch: 0.075mm, 338dpi
Pixel: 2400 x 5600 px
Drive accuracy: 0.01mm
Max Move Speed: X:1500mm/s(with A40640 module 204g), Y:1000mm/s
Frame Material: High precision PC material hybrid frame
Structure Feature: Fit, High precision, stablize, smooth, no oil, easy maintenance, long life
Vertical Carving: Yes (45°)
Motor Size: 42 x 42 x 50mm
Motor Drive Current: 0.9A
Module Height Adjuster:Yes
Home: Rear Left
Origin: Front Left
Compatible Modules: All NEJE 4pin 12V Laser Moudle (Recomend: A40640, N40630, A40630, E40, N30820, N30610, B30635)
MCU: 32-bit 200Mhz MCU (Top 32-bit MCU)
BLE APP control: Yes
MEMS protection: Yes
M7 Control: Yes (For building automatic smoke extraction systems)
M8 Control: Yes (For building automatic air assist systems)
Door Control: Yes (Emergency Suspension and Safety Door Control)
Limit Switch: Yes
ON/OFF Switch: Yes
Input: DC 5.5 2.1, 12V 4A or 5A (Power Adapter)
System: Win 7 / Win 8/ Win 10, Android, iOS, ipadOS, macOS, HarmonyOS.
File format supports: SVG/DXF/JPG/JPEG/PNG/BMP/TIF/CR2, etc.
OTA Upgrade: Yes
NEJE Win Software: Yes, It is recommended to open the NEJE software to update to the latest firmware for the first time use.
Lightburn and LaserGRBL: Yes, improved low light function, added M8, M7, emergency stop extended automatic control, optimized GRBL interaction.
Off-Line Working: Yes, In NEJE Win software and NEJE APP mode, when the image is transferred to the device, it can work independently from the computer or mobile phone.
Repeat Engraving: Yes, After the engraving or cutting is completed, the device will not lose the location information, if you are not satisfied with the work, you can continue to work.
NEJE Android APP: Yes
NEJE iphone/iPad APP: Yes
NEJE Cloud Gallery Service: Yes

NEJE 5 PLUS EXPANSION DESCRIPTION

M7 relay expansion accessories, can be used to control AC or DC power supply smoke exhaust system, can also be used to control other circuits, used as M8, there are safety risks when operating high-voltage circuits, requiring professional operation; M8 valve expansion accessories, can be used To control the air compressor switch, neje 3 supports accessories expansion, but the relay module, air valve module and Door need to be purchased separately, not included in the product list.

About Air Assist

-It is only necessary to add air assist when cutting plywood larger than 3mm and engraving rubber stamps such as carbonized materials. Air assist below 0.4mpa does not make any sense.

About Roller

-Support almost all rollers, round wine bottles, mugs, ceramic mugs can be engraved.

Hundreds of materials can be applied

The above are real works from NEJE fans. If you have any materials that you do not understand, you can contact our customer service.

Package List

1* Laser engraving machine

1* N40630/A40640/A40630 module

1* 12V 4A power supply

1* European standard adapter

1* Manual

1* Red glasses

1* Data cable

1* wooden board

5* paper

1* pen

1* brush

1* focusing film

4* angle iron

1* alumina film

3* cable tie

5* nut

1* large hexagon wrench

1* small hexagon wrench

1* Open wrench

Please Note

If there is a customs spot check, the customs duty is borne by the customer,hope you can understand.

Do not accept bad reviews and disputes due to tariffs.

Weight 28 kg
Dimensions 17 cm
Brand Name

NEJE

Origin

Mainland China

Hign-concerned Chemical

none

Model Number

NEJE 5 Plus A40640

CNC or Not

CNC

Is Smart Device

YES

Condition

New

Certification

UL

Choice

yes
